OSM Door Panel Specialized Machinary Series｜Industry 4.0 Intelligent Precision Manufacturing System

OSM SE Series servo press brake features advanced servo drive technology, delivering high precision and efficiency for sheet metal bending in door panel manufacturing, enabling smart production upgrades.

SE Series CNC Pure Electric Servo Press Brake

Precision Thin-Sheet Processing Solution for Door Frames

Flexible Bending Center

Intelligent Batch Production Equipment for Metal Door Panels

OSM SH Series servo hydraulic press brake combines servo drive and hydraulic systems, offering high rigidity and stability for sheet metal bending in door panel manufacturing, suitable for diverse production needs.

SH Series CNC Servo-Hydraulic Press Brake

High-Efficiency Metal Door Panel Forming System

OSM Door Panel Specialized Machinery Core Features

Precision Forming Technology

Metal door panels utilize sheet metal forming processes. The OSM CNC press brake achieves millimeter-level bending accuracy through programmable control. Equipped with multi-angle synchronous bending and intelligent pressure compensation, geometric dimension tolerance is controlled within ±0.2mm, significantly enhancing component assembly precision.

Intelligent Producing Capacity

OSM press brakes feature high automation and significantly outperform traditional methods in bending efficiency. They support continuous operation, making them ideal for mass production and meeting the demands of the metal door panel market.

Multi-Layer Safety Protection

OSM press brakes are typically equipped with safety protection devices, such as emergency stop buttons, to ensure operator safety. In metal door panel production, safety is critical, and the machine's safety features can effectively reduce the risk of accidents.

Industrial-Grade Operational Stability

OSM CNC press brakes feature advanced mechanical structures and electrical systems, offering excellent stability and high bending accuracy. The high-rigidity frame and precision transmission system can withstand strong bending forces, ensuring long-term stable operation.

High-Efficiency Metal Door Panel Forming System

SE Series CNC Pure Electric Servo Press Brake

The door frames are made of 304 stainless steel and 6063-T5 aluminum alloy, offering excellent fire resistance. The sheet metal thickness ranges from 1.2 to 1.5 mm, and the cold-rolled process ensures a flatness error of ≤0.3 mm/m. The SE series pure electric servo CNC bending machine (±0.5° accuracy) operates stably in environments ranging from -10°C to 45°C, making it the preferred equipment for the production of multiple types of door frames.

Precision Machining: Dual servo motors drive high-precision heavy-duty screw transmission. CNC system continuously monitors and adjusts screw positions to ensure consistent repeat positioning accuracy;

Energy Efficiency: Hydraulic-free design simplifies maintenance, achieves over 30% power savings compared to conventional models;

Productivity Enhancement: Automatic backgauge system uses servo-driven positioning axes with dual ball screw and slider mechanisms for fast, stable operation. Configurable 1/2/4-axis setups optimize workflow efficiency.

OSM SE Series all-electric servo press brake, high-precision, ideal for bending metal range hood decorative strips.

Intelligent Batch Production Equipment for Metal Door Panels

Flexible Bending Center

Metal door panels are primaly made of 304 stainless steel, steel-wood composite, 6063-T5 aluminum, its thickness range from 0.6mm to 1.5mm and height range from 1800mm to 2100mm. With max bending length 2500mm, OSM's flexible bending center is optimized for large-scale metal door panel production.

Real-time data collection & equipment management;

Multi-axis synchronized control (single positioning);

Automatic loading positioning (eliminates manual realignment).

OSM flexible bending center for metal door panels is designed for complex sheet metal structures, offering automation, high flexibility, and precision to boost intelligent production efficiency.

High-Efficiency Metal Door Panel Forming System

SH Series CNC Servo-Hydraulic Press Brake

Metal door panels are mainly made of 304 stainless steel and 6063-T5 aluminum alloy sheets, with standard thickness ranging from 0.6 to 1.5 mm, and height suitable for standard door openings of 1800 to 2100 mm. OSM's SH series servo-hydraulic press brake excel in:

Fast & Efficient: 10% performance boost, 50% higher energy efficiency by reducing cycle time;

Precise & Flexible: Positioning accuracy 0.01mm, stroke up to 400mm, with closed-loop Y1/Y2 pressure correction;

Quality Assurance: Upper & lower dies (wedge-type fine adjustment + mechanical auto-compensation axis) ensure consistent bending angles from 500–3200mm;

Cost Optimization: Greatly reduced hydraulic oil usage, lower maintenance and service costs;

Integrated Stability: Servo pump + integrated pressure filter for higher stability, efficiency, and longer lifespan.
